Name: WINCOO Portable SAW Welding Carriage for Storage Tanks
Brand: Wincoo Engineering Co., Ltd.
SKU: MZ-1250
Price: 2275 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: WINCOO

Certification: CE

Model Number: MZ-1250

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD 2275

Packaging Details: Export package

Delivery Time: 10 days

Payment Terms: L/C, D/A, D/P, T/T

Supply Ability: 100 set/month

Get Best Price

Chat Now

Product Details

Product Description

Highlight:
                                                                                                                                                            portable SAW welding carriage, storage tank welding tractor, tank butt fillet welder


Input Voltage:	AC380±10% Three-phase	Frequency:	50/60 Hz
Rated Capacity:	66 KVA	Rated Input Current:	9A
No Load Voltage:	Submerged Arc Welding: 90V Manual Arc Welding: 75V

Input Voltage:	AC380±10% Three-phase
Frequency:	50/60 Hz
Rated Capacity:	66 KVA
Rated Input Current:	9A
No Load Voltage:	Submerged Arc Welding: 90V Manual Arc Welding: 75V

WINCOO Portable SAW Welding Carriage for Storage Tanks

WINCOO ENGINEERING CO., LTD. proudly presents its state-of-the-art Portable SAW (Submerged Arc Welding) Carriage, specifically engineered for the fabrication and maintenance of large storage tanks. This compact, easy-to-transport unit brings automated, high-quality welding directly to the job site, eliminating the need for bulky, fixed installations.

Technical Specifications

Model	MZ-1250
Input Voltage	AC380±10% Three-phase
Frequency	50/60 Hz
Rated Capacity	66 KVA
Rated Input Current	94A
Current Regulation Range	60-1250 A
Load Duty Cycle	100%
No Load Voltage	Submerged Arc Welding: 90V Manual Arc Welding: 75V
Welding Wire Diameter	1.6-6 MM
Efficiency	95%
Insulation Level	F
Protection Level	IP21S
Dimensions	950 x 450 x 970 mm
Weight	133 KG

Key Features

Ultra-Portable Design: Modular and lightweight for easy transport, setup, and movement around tanks
Robust Construction: Durable aluminum and steel frame ensures stability during operation
Precision Control: Features smooth speed adjustment and a clear digital display for accurate weld parameter monitoring
Versatile Mounting: Easily clamps onto tank edges (vertical) or runs on tracks (horizontal/circumferential)

Core Advantages

Dramatically Increases Productivity: Automates long seam welds, significantly faster than manual methods
Ensures Superior Weld Quality: Delivers consistent, uniform, and defect-free welds with excellent penetration
Reduces Labor & Costs: Minimizes operator fatigue, lowers skill requirements, and reduces rework
Enhances Site Flexibility: Perfect for remote locations, field construction, and confined spaces

Application Directions

Ideal for longitudinal and circumferential welding of:

Large Storage Tanks: Oil, water, chemical, and LNG storage tanks
Pressure Vessels & Silos
Shipbuilding & Offshore Structures
Heavy Plate Fabrication
