Product Details
Place of Origin: Jiangsu, China
Brand Name: WINCOO
Payment & Shipping Terms
Price: $6,500.00/sets 1-99 sets
|
Applicable Industries:
|
Manufacturing Plant, Construction Works
|
Showroom Location:
|
None
|
Video Outgoing-inspection:
|
Provided
|
Machinery Test Report:
|
Provided
|
Marketing Type:
|
New Product 2020
|
Warranty Of Core Components:
|
1 Year
|
Core Components:
|
Motor
|
Condition:
|
New
|
Forming Time:
|
Standard
|
Welding Mode:
|
Tig/Mig/MAG/SAW(optional)
|
Welding Diameter:
|
80mm
|
Dimensions:
|
245*520*290mm
|
Use:
|
Tank Seam Welding
|
Voltage:
|
220V
|
Warranty:
|
1 Year
|
Key Selling Points:
|
Automatic
|
Weight (KG):
|
10.4 KG
|
Power (kW):
|
4
|
Product Name:
|
Tank Welding Machine
|
Application:
|
Tank Construction
|
Working Mode:
|
Auto Seam Welder
|
Welding Method:
|
MAG Welding
|
COLOR:
|
CUSTOMER
|
Welding Material:
|
Carbon Steel Stainless Steel Aluminum
|
|
Applicable Industries:
|
Manufacturing Plant, Construction Works
|
|
Showroom Location:
|
None
|
|
Video Outgoing-inspection:
|
Provided
|
|
Machinery Test Report:
|
Provided
|
|
Marketing Type:
|
New Product 2020
|
|
Warranty Of Core Components:
|
1 Year
|
|
Core Components:
|
Motor
|
|
Condition:
|
New
|
|
Forming Time:
|
Standard
|
|
Welding Mode:
|
Tig/Mig/MAG/SAW(optional)
|
|
Welding Diameter:
|
80mm
|
|
Dimensions:
|
245*520*290mm
|
|
Use:
|
Tank Seam Welding
|
|
Voltage:
|
220V
|
|
Warranty:
|
1 Year
|
|
Key Selling Points:
|
Automatic
|
|
Weight (KG):
|
10.4 KG
|
|
Power (kW):
|
4
|
|
Product Name:
|
Tank Welding Machine
|
|
Application:
|
Tank Construction
|
|
Working Mode:
|
Auto Seam Welder
|
|
Welding Method:
|
MAG Welding
|
|
COLOR:
|
CUSTOMER
|
|
Welding Material:
|
Carbon Steel Stainless Steel Aluminum
|
|
Reference Product Parameter
|
|
|
|
|||
|
Items
|
Parameter
|
|
Notes
|
|||
|
|
Straight rail type
|
Soft rail type
|
|
|||
|
External power source
|
AC 220V 50/60 Hz
|
|
Three-hole
|
|||
|
Working power source
|
AC 20V
|
|
Use of each driver
|
|||
|
Dimensions
|
245*520*280cm
|
245*520*290cm
|
Length*width*height
|
|||
|
Weight
|
8.6 kg
|
10.4 kg
|
Main host
|
|||
|
Track type
|
Linear motion guide
|
Self-aligning flexible slide rails
|
|
|||
|
Drive mode
|
Gear drive
|
Sprocket drive
|
|
|||
|
Welding speed
|
0~1650mm/min
|
|
Fastest
|
|||
|
The thinnest adsorption plate thickness
|
3mm
|
|
Magnetically attractive metal
|
|||
|
Welding gun adjustment range
|
65mm
|
|
Inching for up and down
|
|||
|
|
80mm
|
|
Inching for left and right
|
|||
|
|
+ -60°
|
|
Swinging angle
|
|||
|
|
+ -25°
|
|
Marching Angle
|
|||
|
|
Stop left, stop right
|
|
Swinging form
|
|||
|
Operating function
|
0-100mm/min
|
|
Swinging speed
|
|||
|
|
0-2.5s
|
|
Left and right residence time
|
|||
|
|
+-14mm
|
|
Swinging width
|
|||
|
|
+-5mm
|
|
Center for compensation
|
|||
